Your door runs on one of two counterbalance systems, and which one it is decides the parts, the price and the safety rules. It takes about ten seconds to tell them apart. Most people have never been shown how.
How the two counterbalance systems differ, and why it changes the repair.
Ring three garage door companies about a broken spring and you will get three prices that are nowhere near each other. That is not always because one of them is trying it on. It is often because none of them asked which spring system is on your door, and the two systems are not the same job.
There are only two in a residential garage. Ten seconds of looking will tell you which one you own, and once you know, every other question on the phone gets easier.
Close the door. Go into the garage. Turn and face the door from the inside.
Now look at the wall directly above the opening, in the strip between the top of the door and the ceiling.
If there is a steel bar running horizontally across that wall, with one or two tightly wound springs threaded onto it and a bracket in the middle, you have torsion. The bar is the torsion shaft. At each end of it, above the corners of the door, you will see a grooved wheel with a cable coming off it. Those are the cable drums.
If that wall is bare, look up and back instead. The two horizontal tracks run from the top of the door toward the rear of the garage at ceiling height. A long coiled spring lying parallel to each track, one on the left and one on the right, is an extension system.
That is the whole test. Bar above the door means torsion. Springs beside the tracks means extension. Every residential door in Huntington Beach is one or the other, and nothing else looks like either of them.
Both systems do the same job, which is to counterbalance the weight of the door so the opener, or your arm, only has to overcome friction rather than three hundred pounds of steel.
They go about it in opposite ways.
Torsion stores energy by twisting. The spring is wound onto the shaft, and as it unwinds it turns the shaft, the drums take up the lift cables, and the door rises. The energy is held in the torsion of the wire itself.
Extension stores energy by stretching. Each spring is anchored at the front and pulled back as the door comes down, and it contracts to lift.
From that one difference, everything else follows. Torsion parts are heavier and cost more. Torsion has fewer wear points in the load path. Extension needs pulleys and more cable, which is more to go wrong, but it needs almost no headroom, which is why it is on so many older garages here.
The repair method diverges completely too. A torsion job is about winding, in controlled quarter turns, with two properly sized steel bars. An extension job is about unloading, which means the door goes fully open and gets clamped before anything is unhooked.
If you found long springs beside your tracks, look again at one of them, at the end nearest the back of the garage.
There should be a thin steel cable coming out of the middle of the coil and looping around the hanger. Follow it forward along the inside of the spring. It should be anchored at the front end as well.
That is a containment cable, sometimes called a safety cable. In normal operation it does absolutely nothing. It hangs slack inside the spring for years.
It matters at one moment. An extension spring at full stretch, which is when the door is closed, is holding a great deal of energy along its own axis. When it breaks, that energy releases along that axis, and without a cable running through the middle, the broken half travels. It goes down the length of the garage at roughly the height of a car windscreen. People have been badly hurt this way, and so have cars, water heaters and drywall.
With the cable threaded through, the identical failure is a loud bang and a broken spring hanging on a wire.
Bare extension springs are common on older doors, usually because the springs were replaced at some point by someone who did not fit new cables. If yours are bare, deal with it. It is one of the cheapest items on the whole assembly and there is no sensible argument against it.
Torsion systems do not need containment cables, because a torsion spring is captive on the shaft. It cannot go anywhere when it breaks. It just unwinds with a noise like a shot and the door becomes very heavy.
Springs are not rated in years. They are rated in cycles, and one cycle is one full open plus one full close.
The standard residential spring is built for ten thousand cycles. High cycle springs, made from heavier wire wound to a larger inside diameter, are rated at twenty five thousand. Some manufacturers sell intermediate ratings as well.
Turning that into years takes honest arithmetic about your own household.
This is why a spring failing at year four is not necessarily a defective spring. It may be a correctly rated spring that got used ten thousand times.
It is also why the high cycle upgrade is worth money to some households and worth nothing to others. On ten cycles a day, moving from ten thousand to twenty five thousand cycles takes you from under three years to around seven. On two cycles a day you are extending a thirteen year part to a thirty year one, and the door will be replaced long before the spring is.
Ask before you pay for the upgrade. Anyone who recommends it without asking how often the door runs is not doing the arithmetic.
Cycle ratings assume a spring that is dry and clean. Within a mile or two of the water in Huntington Beach, that is not the environment.
Corrosion works in between the coils. A rusted spring binds slightly against itself instead of winding and unwinding cleanly, and that friction fatigues the wire faster than the cycle count alone predicts. On extension systems the pulleys suffer first and worst, because a seized pulley sheave stops rotating and the cable starts sawing over a fixed surface.
Coated or galvanized springs cost a little more and are worth it near the sand. A few miles inland it stops mattering much.
On a door with two springs, both come off, every time. This is worth understanding rather than taking on trust.
The two springs are the same age and have done the same number of cycles under the same load. The one that has not failed yet is not healthy. It is simply a few weeks or months behind its twin.
There is a mechanical reason as well as an economic one. A new spring and a fatigued spring do not pull with the same force. The door then lifts harder on one side, which loads one drum or one pulley more than the other, drags a roller in the track, and puts a twist through the top section on every cycle.
The economics point the same way. Nearly all the labour in a spring job is getting the tension off and back on again safely. Once that is done, the second spring costs the price of the spring and a few minutes. Doing it separately in six months costs another whole visit.
Mixing systems is not a thing either. Nobody runs a torsion spring above the door and extension springs on the tracks. If you think you are looking at both, what you are probably seeing is an old extension system left in place and abandoned when a torsion conversion was done, which is untidy but harmless.
We are relaxed about homeowners doing their own work. Rollers, hinges, the bottom weather seal, hosing the sand out of the bottom track, checking that the photo eyes are aligned so the UL 325 reversing system actually works. All fine, all worth doing.
Springs are the exception, on both systems.
A wound torsion spring holds enough energy to break bones if a winding bar slips, and the accidents happen to competent people who used a screwdriver or a bar that was the wrong diameter for the cone. There is no gentle version of that failure.
A stretched extension spring is safe to handle only after the door is fully open and physically secured so it cannot come down. Get that sequence out of order and the spring releases while you are holding it.
Neither of these is a skill problem. It is that the margin for a mistake is zero, and the tools that make it safe are specific tools rather than whatever is on the bench.
Three pieces of information and we can quote the job properly rather than guessing.
That last one matters. If a spring has gone, leave the door closed and leave the opener alone. An opener asked to lift an uncounterbalanced door will strip its gear or bend the top section trying, which turns a spring job into a spring job plus a section.
Call Brandedvideo at (657) 704-2227.
Different hardware, different method, different tools. We carry both.
Two systems, two price shapes. Torsion parts cost more and last longer. Extension parts are cheaper and there are more of them.
Brandedvideo works on garage door springs in Huntington Beach. Not openers as a headline act, not new doors as an upsell. The counterbalance, which is the part carrying between one hundred and four hundred pounds of door every time you press the button.
There are only two ways that job gets done in a residential garage. A torsion system puts one or two wound springs on a steel shaft mounted horizontally above the opening, and the shaft turns cable drums that lift the door. An extension system puts a long stretched spring alongside each horizontal track, running back toward the rear of the garage, pulling through a pulley and cable.
They do the same work by opposite means. One stores energy by twisting, the other by stretching. Almost everything that follows from that, the parts, the failure behaviour, the safety hardware and what a repair costs, is different. So the first honest question on the phone is not what is wrong. It is which system are we looking at.
Spring calls across Huntington Beach and the neighbouring cities, with both systems on the van.
Call (657) 704-2227. If a spring has already broken, leave the door down and leave the opener alone.
Thirty seconds inside the garage tells us most of what we need. Shaft above the opening with springs on it, or long springs beside the ceiling tracks. Tell us which, tell us whether the door is single or double, and we can quote the job properly instead of guessing on the phone.
